sfc8100bt-bp_4x4
1Gbps TP 8포트 + 10G SFP 4슬롯, PoE 240W, 동작온도: -40~80°C, BYPASS 4×4, 산업용 스위치
sfc8100bt-bp_4x4
1Gbps TP 8포트 + 10G SFP 4슬롯, PoE 240W, 동작온도: -40~80°C, BYPASS 4×4, 산업용 스위치
Key Features
- 10/100/1000Mbps TP 8PoE +100M/1G/10Gbps SFP+ 4슬롯
- Fiber BYPASS LC type 4 X 4
- 웹 관리, 콘솔, Telnet, SSH, SNMP, RMON, Syslog
- Scan Manager Program 지원
- STP(IEEE 802.1D) / RSTP(IEEE802.1w) /MSTP(IEEE802.1s)
- Port VLAN & VLAN Tagging(IEEE802.1Q)
- S-Ring(절체, 복구 30ms), Dual-Ring
- Carrier Ethernet (G.8032 ERPS)
- IP Multicast support (IGMP/MLD)
- Priority Queue Support (8 Queue per port)
Download
Specifications
Standards
IEEE 802.3/3u 10BaseT/100BaseTX and 100BaseFX
IEEE 802.3ab/3z 1000BaseT/1000Base-X Fiber
IEEE 802.3ae 10 Gigabit Ethernet
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1s Multiple Spanning Tree Protocol
IEEE 802.1Q VLAN Tagging
IEEE 802.3ad Port trunk with LACP
ITU-T G.8032 Ethernet Ring Protection Switching
IEEE 802.3af/at/bt Power over Ethernet
TP 포트
광 포트(10G)
콤보 포트
BYPASS 포트
8 TP(1Gbps)
10G SFP 4슬롯
-
LC Type 4x4
POE포트
4 PoE(af/at) + 4 PoE(af/at/bt)
PoE Max. 240W
Switch Fabric
Throughtput
Memory(RAM)
Flash Memory
MAC Table
Jumbo Frame
96Gbps
71.4Mpps
256MB
16MB
32K
10K
IEEE 802.1x NAC
802.3ad LACP
IGMP Snooping
STP/RSTP/MSTP
G.8032 ERPS Ring
S-Ring
O
O
O
O
O
O
입력전원
무부하전력
최대전력
전원이중화
DC 54~56V
15.9W
267.2W
O
동작온도
설치방법
크기
-40ºC ~ 70ºC
Wall or Din-Rail Mount
74(W) x 130(D) x 166.5(H)mm
